2.0mm Dynamic Compression Plates
- Made from high precision CNC machined 316LVM for exceptional dimensional consistency and microstructural homogeneity
- Post-processed with a micro-beaded surface treatment to maximize mechanical property performance, biocompatibility and reflective glare control in the OR
| SKU | # OF HOLES | LENGTH (mm) | WIDTH (mm) | THICKNESS (mm) |
| PDCP20/04 | 4-Hole | 23.00 | 5.00 | 1.00 |
| PDCP20/05 | 5-Hole | 28.00 | 5.00 | 1.00 |
| PDCP20/06 | 6-Hole | 33.00 | 5.00 | 1.00 |
| PDCP20/07 | 7-Hole | 38.00 | 5.00 | 1.00 |
| PDCP20/08 | 8-Hole | 43.00 | 5.00 | 1.00 |
| PDCP20/09 | 9-Hole | 48.00 | 5.00 | 1.00 |
| PDCP20/10 | 10-Hole | 53.00 | 5.00 | 1.00 |
| PDCP20/11 | 11-Hole | 58.00 | 5.00 | 1.00 |
| PDCP20/12 | 12-Hole | 63.00 | 5.00 | 1.00 |
| PDCP20/13 | 13-Hole | 68.00 | 5.00 | 1.00 |
| PDCP20/14 | 14-Hole | 73.00 | 5.00 | 1.00 |
| PDCP20/16 | 16-Hole | 83.00 | 5.00 | 1.00 |
Specifications
| Plate # of Holes | 4-Hole or 5-Hole or 6-Hole or 7-Hole or 8-Hole or 9-Hole or 10-Hole or 11-Hole or 12-Hole or 13-Hole or 14-Hole or 16-Hole |
| Locking or Non-Locking | Non-Locking |
| Plate Type | 2.0 |
| Broad Plate | No |
| Limited Contact Plate | No |
